100 mm to 400mm
As per IS : 2062-99 Grade 'A', 'B' & 'C'
Beams
Jain's I-Beam
Special Feature
- Low temperature rolling imparts higher strength to the structures.
- Pilling and automatic tying of the structurally ensure minimum damage during handling and transport.
- Invoicing : As per actual weight.
Item |
Size(mm) |
Sec.Wt. |
Sec.
Area,a |
D |
B |
T |
T |
kg/m |
kg/m |
mm |
mm |
mm |
mm |
||
ISMB IPE IPE ISMB ISMB ISMB ISMB IPE IPE ISMB IPE IPE ISMB IPE ISMB IPE IPE ISMB ISMB |
100X50 100x50 100x55 125x70 140x66 150x75 175x85 200x90 200x100 200x100 240x106 240x120 250x125 300x125 300x140 340x137 300x150 350x140 400x140 |
8.90 8.00 8.10 13.30 14.30 15.00 19.60 26.20 22.40 24.20 36.20 30.70 37.30 54.20 46.00 68.00 42.20 52.40 61.50 |
11.40 10.20 10.30 17.00 18.20 19.10 25.00 33.40 28.50 30.80 46.10 39.10 47.50 69.10 58.60 86.60 53.80 66.70 78.40 |
100 100 100 125 140 150 175 200 200 200 240 240 250 300 300 340 300 350 400 |
50 50 55 70 66 75 85 90 100 100 106 120 125 125 140 137 150 140 140 |
4.7 4.0 4.1 5.0 5.7 5.0 5.8 7.5 5.6 5.7 8.7 6.2 6.9 10.8 7.7 12.2 7.1 8.1 8.9 |
7.0 6.4 5.7 8.0 8.6 8.0 9.0 11.3 8.5 10.0 13.1 9.8 12.5 16.2 13.1 18.3 10.7 14.2 16.0 |
